1. Push Button Switches: An Overview
CN·SL push button switches are essential control components widely used in industrial automation, automotive systems, electronics, and various electrical control applications. We offer a full range of sizes—from compact designs to heavy-duty industrial models—including 12mm, 16mm, 19mm, 22mm, 25mm, and 30mm. Whether you need to turn equipment on/off or trigger a specific action, CN·SL push button switches deliver stable, efficient, and reliable operation.
2. Key Functions of Push Button Switches
The main functions of CN·SL push button switches include:
Circuit control – Opening or closing electrical circuits
Device activation – Triggering or stopping device operations
Mode selection – Using momentary or latching structures to switch modes
Status indication – Options with built-in LEDs to display operation status
These functions make them suitable for a wide variety of mechanical and electrical systems.
3. Applications
CN·SL push button switches are highly versatile and commonly used in:
Industrial automation – Control panels, machinery, production lines
Automotive and transportation – Vehicle modifications, electrical systems
Consumer electronics – Computers, audio equipment, smart devices
Marine and outdoor equipment – Boat consoles, outdoor lighting
Commercial equipment – Vending machines, access control, power boxes
Their durability, reliability, and attractive appearance make them indispensable control components across multiple industries.
4. Technical Specifications
Depending on the model, CN·SL push button switches feature:
Mounting hole sizes: 12mm / 16mm / 19mm / 22mm / 25mm / 30mm
Operation types: Momentary or Latching
Protection rating: Up to IP65 / IP67 (model-dependent)
Rated voltage & current: 12V, 24V, 110V, 220V, and others
Contact configurations: NO, NC, or NO+NC
Mechanical life: Up to 500,000–1,000,000 cycles
Exact specifications vary by model, allowing you to select the ideal switch for your application.
5. How They Work
A push button switch operates through a simple but reliable mechanical principle:
When the button is pressed, the internal mechanism moves the contacts, allowing the circuit to connect (ON) or disconnect (OFF).
This proven mechanical design ensures consistent performance in demanding environments.
6. Key Components of a Push Button Switch
CN·SL push button switches typically consist of:
Actuator (Button head) – The part touched by the user; available in metal, plastic, illuminated or non-illuminated
Housing – Protects internal parts and provides structural strength
Spring mechanism – Enables momentary or latching operation
Electrical contacts – Conduct or interrupt electrical current
LED module (optional) – Provides visual indication
Mounting hardware – Ensures secure installation on panels
Each component contributes to durability, functionality, and user experience.
7. Push Button Switches Operation Methods
Operation methods include:
Momentary – Activates only when pressed
Latching – Remains in the switched position until pressed again
Illuminated type – Adds visual feedback
Waterproof type – Designed for outdoor and moist environments
Flat-head / High-head / Dome-head options – Customizable for different tactile and aesthetic needs
Users can choose the most suitable operation style based on their application.
8. Materials Used in Push Button Switches Manufacturing
To ensure durability and safety, CN·SL push button switches use high-quality materials:
Metal actuator – Stainless steel, aluminum alloy, or zinc alloy for corrosion resistance
Housing materials – PA66, nylon, or metal bodies for enhanced strength
Contact materials – Silver alloy for superior conductivity and longevity
Sealing materials – Silicone or rubber rings for dustproof and waterproof protection
LED components – High-brightness, low-power light modules
These premium materials ensure our switches remain stable, durable, and safe in diverse environments.
