Modular Assembly Flexibility: The three - piece structure of the switch provides high flexibility in module installation. It can accommodate up to 6 groups of modules, and three groups of contact modules can be combined horizontally. This modular combination allows users to tailor the switch's configuration according to their specific needs, making it adaptable to a wide range of electrical setups
Compact Size: With its small size, the SLA6 switch is well - suited for miniaturized cabinets. It can meet the wiring needs of scenarios where multiple groups of contact modules are required, making it an ideal choice for applications with limited space, such as in compact control panels or small - scale electrical systems.
Technical parameters
Rated Insulation Voltage Ui: The rated insulation voltage Ui of the switch is 660V (AC 50/60Hz). This value represents the maximum continuous voltage that the insulation within the switch can safely endure over an extended period, preventing electrical leakage and ensuring user safety
Conventional Free Air Heating Current Ith: The conventional free air heating current Ith is 10A. This parameter indicates the maximum current that the switch can continuously carry in free air without causing excessive temperature rise, ensuring reliable performance under normal operating conditions.
