Performs optimally within an ambient temperature span of -25°C to +50°C. Moreover, the daily average temperature must not exceed +35°C to ensure sustained performance.
Storage Temperature
Can be safely stored in environments with temperatures ranging from -30°C to 70°C, preserving the product's integrity when not in use.
Technical parameters
Conventional Heating Current (Ith)
Under normal operating circumstances, the conventional heating current is 3 amperes (A), indicating the typical current flow during operation.
Contact Resistance
Features a contact resistance of 50 milliohms (mΩ) or lower, ensuring minimal electrical resistance and efficient electrical connection.
Shock Capacity (Ue/Ie)
AC - 15: Rated for 220 volts (V) and 0.5 amperes (A) under alternating current conditions
DC - 13: Rated for 24 volts (V) and 0.7 amperes (A) under direct current conditions.
