SLA1H-XD
CN·SL
Structural feature
Mechanical lif
Fat button (self-healing) ≥1 million times.Mushroom/with light button (self-resetting) ≥ 600,000 times,Knob/key knob/self-locking knob ≥ 100,000 times
Electrical life:
≥ 100,000 times under quota load
Conventional Heating Current (Ith)
Under normal operating conditions, the conventional heating current is 3 amperes (A), indicating the typical current flow during operation.
Contact Resistance
Exhibits a contact resistance of 50 milliohms (mΩ) or less, ensuring low electrical resistance and efficient electrical connection.
Shock Capacity (Ue/Ie)
AC - 15: Rated for 220 volts (V) and 0.5 amperes (A) under alternating current conditions.
DC - 13: Rated for 24 volts (V) and 0.7 amperes (A) under direct current conditions.
